Philips PM 5390 - General Description; Logic Symbol; Connection Diagram Dip

11-5
11
C
90
10/11
PRESCALER
GENERAL
DESCRIPTION
-
The
11C90
is
a
high
speed
prescaler
designed
specifically
for
com-
munication
and
instrumentation
applications. It
will
divide by
either 10 or
11
over
a
frequency
range
from
dc
to
typically
650 MHz.
The
division
ratio is
controlled by
the mode
control. The di-
vide
by
10
or
11
capability
allows
the use
of
pulse
swallowing
techniques
to
control high
speed
counting
moduios
by
lower
speed
circuits.
The
1
1
C90
may be
used with either
ECL or TTL
power
supplies.
In
addition
to
the
ECL
outputs
Q4
and
Q4,
the 1
1C90
contains
an ECL-to-TTL
converter and
a TTL
output.
The
TTL
output
operates
from the
same
Vqq
and Vgg
levels as the
counter,
but a
separate
pin
is
used
for
the
TTL
circuit This
minimizes
noise
coupling
when the
TTL
output
switches
and
also
allows
power
consumption
to
be
reduced
by
leaving the
separate Vgg
pin open
if the
TTL
out-
put
is
not
used.
To
facilitate
capacitive
coupling of the
clock
signal,
a 400 Q
resistor
(Vp^p)
Is
connected
internally
to
the
V33
reference.
Connecting this
resistor to
the
Clock Pulse
input
(CP)
automatically
centers
the
input
signal
about
the
switching
threshold.
Maximum
frequency operation
is
achieved
with
a
50%
duty
cycle.
Each
of the
Mode
Control
inputs is
connected
to
an
internal
2
k resistor with the
other end
uncom-
mitted
(RM-j
and
RM2).
An M
input
can
be
driven from
a TTL circuit
operating from the
same Vqq
by
connecting
the
free
end of the
associated
2 k
resistor
to
When
an
M
input
is
driven
from
an
ECL
circuit,
the
2
k
resistor can
be left
open or,
if required,
can
be
connected
to
V33 to act as a
puH-down
resistor.
The device is
packaged
in a
hermetic
16-pin
ceramic
Dual
In-line package.
It
is
available in
commercial
and military
temperature
ranges.
•
VERY
HIGH
SPEED
-
650 MHz
TYPICAL
• DIVIDE
BY
10/11
MODE CONTROL
•
OPERATES
FROM
TTL
OR ECL
POWER
SUPPLY
•
HIGH
SPEED
TOTEM POLE TTL OUTPUT
-
20
mA FAN-OUT
•
COMPLEMENTARY
ECL
OUTPUTS
DRIVE
50
Q
LINES
•
SEPARATE
TTL
GND {Vgg)
PIN MINIMIZES NOISE
COUPLING
•
PULL-UP
RESISTORS
ON MODE
CONTROL
INPUTS FOR
TTL
COMPATIBILITY
• INTERNAL
BIASING
REFERENCE
FOR
AC
COUPLED CLOCKING
• INTERNAL
50
kO
INPUT PULL-DOWNS
-
UNUSED
INPUTS
MAY BE LEFT
OPEN
•
COUNT
ENABLE
CONTROL FOR GATED
CLOCKING
•
ASYNCHRONOUS
MASTER
SET FOR
INITIALIZING
PINJJAMES
CE
CP
Mn
MS
04,04
om
RMn
''ref
Count
Enable
Input
{Active LOW)
Clock Pulse Input
Count
Modulus
Control
Input
Asynchronous
Master Set
Input
Complementary
ECL
Outputs
TTL
Output
2
k Resistor to M^
400
O
Resistor to
V3g
LOGIC
SYMBOL
2 3
Vcc=Pin4
VgE=
Pin 12
Vee
(TTL)
=
Pin
13
CONNECTION
DIAGRAM
DIP
(TOP VIEW)
