Alignments
EN 70 SDI PDP8.
8.9 Alignment value overview (all screens)
Table 8-1 Alignment table Y PWB
Model Wave Form Item Default
37”SD v4 Rising_Ramp VR5001 30 µs (30 ~ 40)
Falling_Ramp_1st VR5002 16 µs (10 ~ 20)
Vsch VR5000 38 V
42” SD v2 Rising_Ramp (Vset) VR5003 10 µs
-Vsc 1 VR5001 20 µs
-Vsc 2 VR5002 5 µs
42” SD v3 Rising_Ramp VR5002 10 µs
Falling_Ramp_1st VR5003 30 µs
Falling_Ramp_3rd VR5001 30 µs
Vsch VR5004 40 V
42” SD v4 Rising_Ramp VR5001 60 µs
Falling_Ramp_1st VR5003 80 µs
42” HD v3 Rising_Ramp VR5002 10 µs
Falling_Ramp_1st VR5003 20 µs
Falling_Ramp_3rd VR5001 10 µs
Vsch Scan high voltage VR5004 40 V
42” HD v4 Rising_Ramp VR5001 15 V
Falling_Ramp_1st VR5002 50 µs
50” HD v3 Rising_Ramp VR5000 50 µs
Falling_Ramp_1st VR5001 35 µs
Falling_Ramp_3rd VR5002 20 µs
Vsch Scan high voltage VR5901 25 V
50” HD v4 Rising_Ramp VR5001 90 µs
Falling_Ramp_1st VR5003 80 µs
