5. Service Modes, Error Codes, and Fault Finding
Index of this chapter:
5.1 Repair Tools
5.2 Fault Finding
5.3 Defect Description Form
5.1 Repair Tools
5.1.1 ComPair
For the v3 and v4 models, it will be possible to generate test
patterns with ComPair. The ComPair interface must be
connected to the Logic Board with the special interconnection
cable (see table below for the order code).
5.1.2 Other Service Tools
Table 5-1 Overview Service tools
Figure 5-1 Foam buffers
Figure 5-2 V2 jig
Figure 5-3 V3 jig
Service Tools
Order Code
Jumper J8002 + V2 JIG connector kit 3122 785 90760
V3 JIG connector + for SDI panel repair 3122 785 90770
Jumper J8002 to be used in connector kit 3122 785 90780
V2 JIG connector to be used in conn. kit 3122 785 90790
ComPair / SDI interconnection cable 3122 785 90800
Foam buffers (2 pcs.) 3122 785 90581
F_14991_031.eps
030805
3122 785 90760
F_14991_030.eps
030805
3122 785 90770
