Spare Parts List
EN 73SDI PDP 10.
Table 10-2 Spare parts overview 42” SD v2
Table 10-3 Spare parts overview 42” SD v3
Table 10-4 Spare parts overview 42” SD v4 (Part 1)
PDP type 42"SDv2
PDP model 12NC 9322 195 45682
PDP model type and version S42SD-YD06
Remarks
Codes for lead type PWBs (this model has been produced
with leaded type PWB's only)
Boards PWB Codes
Logic-Buffer (E) LJ92-00632A 9965 000 17726
Logic-Buffer (F) LJ92-00633A 9965 000 17725
Logic-Buffer (G) LJ92-00634A 9965 000 17724
Logic-Buffer (H) - -
Logic-Buffer (I) - -
Logic-Buffer (J) - -
Y-Buffer (up) LJ92-00751A 9965 000 17727
Y-Buffer (down) LJ92-00750A 9965 000 17728
Logic-Board LJ92-00818A 9965 000 17729
SUBL - -
SUBR - -
X-Board LJ92-00998A 9965 000 17720
Y-Board LJ92-00999A 9965 000 17731
SMPS (PSU) LJ44-00049A 9965 000 17730
SUB PSU - -
PDP type 42" SD v3
Lead Free type
being compatible
with Lead type
PWB
PDP model 12NC 9322 215 27682
PDP model type and version S42SD-YD06
Remarks Lead type boards being phased out
Boards Codes for leaded type PWBs Codes for lead-free type PWBs
Logic-Buffer (E) LJ92-00811A 9965 000 25109 LJ92-00811B 9965 000 32624 Y
Logic-Buffer (F) LJ92-00812A 9965 000 25110 LJ92-00812B 9965 000 32625 Y
Logic-Buffer (G) LJ92-00813A 9965 000 25111 LJ92-00813B 9965 000 32626 Y
Logic-Buffer (H)-----
Logic-Buffer (I)-----
Logic-Buffer (J)-----
Y-Buffer (up) LJ92-00796A 9965 000 25112 LJ92-01285A 9965 000 32376 Y
Y-Buffer (down) LJ92-00797A 9965 000 25113 LJ92-01286A 9965 000 32377 Y
Logic-Board LJ92-00975D 9965 000 25114 LJ92-01247D 9965 000 32378 N (tbd)
SUBL -----
SUBR -----
X-Board LJ92-00943A 9965 000 25115 LJ92-01283A 9965 000 32627 Y
Y-Board LJ92-00944B 9965 000 25116 LJ92-01284A 9965 000 32379 Y
SMPS (PSU) LJ44- 000 58A 9965 000 25108 LJ44-00058B 9965 000 32638 Y
SUB PSU LJ44- 000 75A 9965 000 25131 LJ44-00075B 9965 000 32623 Y
PDP type 42" SD v4
Boards from
PP42SD015A
and
S42SD-YD07 (*)
being
compatible
PDP model 12NC 9322 226 37682
PDP model type and version S42SD-YD07 (*) S42SD-YD07 (PP42SD015A)
Remarks
No supply of new SMPS LJ44-00092B.
Compatibility with LJ44-00101C + cable: tdb (15/2)
Version number used by SDI:PP42SD015B(SMPS Rev.0.55)
New SMPS supply:LJ44-00101C + cables. Service
information: tbd
Logic-Buffer (E) LJ92-01026A 9965 000 29205 LJ92-01026A 9965 000 29205 Y
Logic-Buffer (F) LJ92-01027A 9965 000 29206 LJ92-01027A 9965 000 29206 Y
Logic-Buffer (G) - - - - -
Logic-Buffer (H) - - - - -
Logic-Buffer (I) - - - - -
Logic-Buffer (J) - - - - -
Y-Buffer (up) LJ92-01031A 9965 000 29207 LJ92-01031A 9965 000 29207 Y
Y-Buffer (down) LJ92-01032A 9965 000 29208 LJ92-01032A 9965 000 29208 Y
Logic-Board LJ92-01274D 9966 000 30042 LJ92-01274D 9966 000 30042 Y
SUBL -----
SUBR -----
X-Board LJ92-01029A 9965 000 29204 LJ92-01336A 9965 000 32628 Y
Y-Board LJ92-01030A 9965 000 29209 LJ92-01337A 9965 000 32629 Y
SMPS (PSU) LJ44-00092B 9965 000 29210 LJ44-00101A 9965 000 29210 N (tdb)
SUB PSU-----
