Spare Parts List
EN 75SDI PDP 10.
Table 10-8 Spare parts overview 42” HD v4 (Part 2)
Table 10-9 Spare parts overview 50” HD v3
PDP type 42" HD v4 Service
Information 9322
233 80682 being
backwards
compatible tbd
PDP model 12NC 9322 226 95682 9322 233 80682
PDP model type and version S42AX-YD01 (PP42AX-008A) PWB's from
PP42AX-007A
and
PP42AX-008A
being
Compatible
S42AX-YD01 (PP42AX-008B)
PWB's from
PP42AX-008A
and
PP42AX-008B
being compatible
Remarks
(SMPS Rev.0.65) New SMPS supply:LJ44-
00101C + cables. Service information: tbd
(SMPS Rev.0.55) New SMPS supply:LJ44-00101C + cables.
Service information: tbd
Logic-Buffer (E) LJ92-01054A 9965 000 29197 Y LJ92-01054A 9965 000 29197 Y
Logic-Buffer (F) LJ92-01055A 9965 000 29198 Y LJ92-01055A 9965 000 29198 Y
Logic-Buffer (G) - - - - - -
Logic-Buffer (H) - - - - - -
Logic-Buffer (I) - - - - - -
Logic-Buffer (J) - - - - - -
Y-Buffer (up) LJ92-01202A 9965 000 32639 Y LJ92-01202A 9965 000 32639 Y
Y-Buffer (down) LJ92-01203A 9965 000 32640 Y LJ92-01203A 9965 000 32640 Y
Logic-Board LJ92-01270B 9965 000 32641 Y LJ92-01270B 9965 000 32641 Y
SUBL - - - - - -
SUBR - - - - - -
X-Board LJ92-01199A 9965 000 32642 Y LJ92-01199A 9965 000 32642 Y
Y-Board LJ92-01200A 9965 000 32643 Y LJ92-01200A 9965 000 32643 Y
SMPS (PSU) LJ44-00101B 9965 000 32630 N LJ44-00101C 9965 000 33880 Y
SUB PSU - - - - - -
PDP type 50" HD v3
PDP model 12NC 9322 215 26682
PDP model type and version S50HW-XD03 (PP50HW004C)
Remarks Lead type boards being phased out Lead Free type
being compatible
with Lead type
PWB
Boards Codes for leaded type PWBs Codes for lead-free typePWBs
Logic-Buffer (E) LJ92-00917A 9965 000 25117 LJ92-00917B 9965 000 32614 Y
Logic-Buffer (F) LJ92-00918A 9965 000 25118 LJ92-00918B 9965 000 32615 Y
Logic-Buffer (G) LJ92-00919A 9965 000 25119 LJ92-00919B 9965 000 32646 Y
Logic-Buffer (H) LJ92-00920A 9965 000 25120 LJ92-00920B 9965 000 32647 Y
Logic-Buffer (I) LJ92-00921A 9965 000 25121 LJ92-00921B 9965 000 32648 Y
Logic-Buffer (J) LJ92-00922A 9965 000 25122 LJ92-00922B 9965 000 32649 Y
Y-Buffer (up) LJ92-00880A 9965 000 25123 LJ92-00880B 9965 000 32650 Y
Y-Buffer (down) LJ92-00881A 9965 000 25124 LJ92-00881B 9965 000 32651 Y
Logic-Board LJ92-00949C 9965 000 25125 LJ92-01224B 9965 000 32652 Y
SUBL LJ92-00923A 9965 000 25126 LJ92-00923B 9965 000 32653 Y
SUBR LJ92-00959A 9965 000 25127 LJ92-00959B 9965 000 32654 Y
X-Board LJ92-00852A 9965 000 25128 LJ92-00852B 9965 000 32655 Y
Y-Board LJ92-00853A 9965 000 25129 LJ92-00853B 9965 000 32656 Y
SMPS (PSU) LJ44-000 65A 9965 000 25130 LJ44-00065B 9965 000 32657 Y
SUB PSU LJ44-000 99A 9965 000 26195 LJ44-00099B 9965 000 32658 Y
