Philips VR730/02 - L701; L702; L703; L704

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR732/02 VR732/39 VR730/07 VR730/39 VR732/16 VR730/02 VR730/16
L501 4822 157 10649 INDUCTOR 100UH-K-26T 1 1 1 1 1 1 1
L561 4822 157 10649 INDUCTOR 100UH-K-26T 1 1 1 1 1 1 1
L562 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1 1 1 1 1
L581 9965 000 05627 CHOKE COIL 47UH-K 1 1 1 1 1 1 1
L701 4822 157 10889 INDUCTOR 10UH-K-26T 1 1 1 1 1 1 1
L702 9965 000 05627 CHOKE COIL 47UH-K 1 1 1 1 1 1 1
L703 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1 1 1
L704 4822 157 11511 INDUCTOR 15UH-K-26T 1 1 1 1 1
L705 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1 1 1 1 1
L851 9965 000 08629 INDUCTOR 1.8UH-K-26T 1 1 1 1 1 1 1
L853 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1 1 1 1 1
TRANSISTORS
PS503 9965 000 12189 PHOTO INTERRUPTER RPI-302C70 1 1 1 1 1 1 1
Q001 9965 000 06568 FET FS1KM-18A 1 1 1 1 1 1 1
Q002 4822 130 10923 TRANSISTOR KTC3199(BL) 1 1 1 1 1 1 1
Q003 4822 130 10923 TRANSISTOR KTC3199(BL) 1 1 1 1 1 1 1
Q004 4822 130 10103 TRANSISTOR KTC3199(Y) 1 1 1 1 1 1 1
Q051 4822 130 42292 RES. BUILT-IN TRANSISTOR KRA104M 1 1 1 1 1 1 1
Q052 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 1 1 1 1 1 1 1
Q053 4822 130 10103 TRANSISTOR KTC3199(Y) 1 1 1 1 1 1 1
Q054 9965 000 09389 TRANSISTOR 2SD1246(T) 1 1 1 1 1 1 1
Q056 4822 130 10145 RES. BUILT-IN TRANSISTOR KRA103M 1 1 1 1 1 1 1
Q057 9965 000 12190 TRANSISTOR KTA1281(Y) 1 1 1 1 1 1 1
Q058 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 1 1 1 1 1 1 1
Q153 4822 130 10103 TRANSISTOR KTC3199(Y) 1 1 1 1 1 1 1
Q351 4822 130 42959 TRANSISTOR KTA1266(GR) 1 1 1 1 1 1 1
Q352 4822 130 10103 TRANSISTOR KTC3199(Y) 1 1 1 1 1 1 1
Q401 4822 130 42959 TRANSISTOR KTA1266(GR) 1 1 1 1 1 1 1
Q402 4822 130 42292 TRANSISTOR KTC3203(Y) 1 1 1 1 1 1 1
Q403 4822 130 10145 RES. BUILT-IN TRANSISTOR KRA103M 1 1 1 1 1 1 1
Q404 4822 130 10103 TRANSISTOR KTC3199(Y) 1 1 1 1 1 1 1
Q405 4822 130 10103 TRANSISTOR KTC3199(Y) 1 1 1 1 1 1 1
Q406 4822 130 10103 TRANSISTOR KTC3199(Y) 1 1 1 1 1 1 1
Q451 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 1 1 1 1 1 1 1
Q501 4822 130 10923 TRANSISTOR KTC3199(BL) 1 1 1 1 1 1 1
Q502 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 1 1 1 1 1 1 1
Q503 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 1 1 1 1 1 1 1
Q551 4822 130 10923 TRANSISTOR KTC3199(BL) 1 1 1 1 1 1 1
Q552 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 1 1 1 1 1 1 1
Q771 4822 130 10103 TRANSISTOR KTC3199(Y) 1 1 1 1 1 1 1
Q772 4822 130 10103 TRANSISTOR KTC3199(Y) 1 1 1 1 1 1 1
RESISTORS
R001 9965 000 08653 CARBON RES. 1/2W K 5.6M OHM 1 1 1 1 1 1 1
R002 9965 000 08635 METAL OXIDE FILM RES. 1W J 150K OHM 1 1 1 1 1 1 1
R003 CARBON RES. 1/4W J 1M OHM 1 1 1 1 1 1 1
R004 CARBON RES. 1/4W J 1M OHM 1 1 1 1 1 1 1
R005 CARBON RES. 1/6W G 1.5K OHM 1 1 1 1 1 1 1
R006 METAL OXIDE FILM RES. 1W J 2.2 OHM 1 1 1 1 1 1 1
R007 CARBON RES. 1/6W J 22K OHM 1 1 1 1 1 1 1
R008 CARBON RES. 1/6W J 100K OHM 1 1 1 1 1 1 1
R009 CARBON RES. 1/6W G 5.6K OHM 1 1 1 1 1 1 1
R011 CARBON RES. 1/4W J 390K OHM 1 1 1 1 1 1 1
R012 CARBON RES. 1/4W J 390K OHM 1 1 1 1 1 1 1
R013 CARBON RES. 1/6W J 470K OHM 1 1 1 1 1 1 1
R014 CARBON RES. 1/6W J 100K OHM 1 1 1 1 1 1 1
R015 CHIP RES.(1608) 1/10W J 10K OHM 1 1 1 1 1 1 1
R016 CARBON RES. 1/6W J 100K OHM 1 1 1 1 1 1 1
R017 CHIP RES.(1608) 1/10W J 220K OHM 1 1 1 1 1 1 1
R018 CHIP RES.(1608) 1/10W J 22K OHM 1 1 1 1 1 1 1
R021 CHIP RES.(1608) 1/10W J 22K OHM 1 1 1 1 1 1 1
R022 CHIP RES.(1608) 1/10W J 680 OHM 1 1 1 1 1 1 1
R023 CHIP RES.(1608) 1/10W J 2.2K OHM 1 1 1 1 1 1 1
R024 CHIP RES.(1608) 1/10W J 1K OHM 1 1 1 1 1 1 1
1-16-18
