Philips VR730/02 - Tp751; Tu701

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR732/02 VR732/39 VR730/07 VR730/39 VR732/16 VR730/02 VR730/16
R787 CHIP RES.(1608) 1/10W J 2.2K OHM 1 1 1 1 1 1 1
R851 CHIP RES.(1608) 1/10W J 1.5K OHM 1 1 1 1 1 1 1
R852 CHIP RES.(1608) 1/10W J 1K OHM 1 1 1 1 1 1 1
R853 CHIP RES.(1608) 1/10W J 1K OHM 1 1 1 1 1 1 1
RS501 9965 000 12287 REMOTE RECEIVER MIM-93M9DKF 1 1 1 1 1 1 1
SA001
h
SURGE ABSORBER PVR-10D471KB 1 1 1 1 1 1 1
SWITCHES
SW501 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW502 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW504 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW505 4822 276 13954 TACT SWITCH KSM0614B 1 1 1 1 1 1 1
SW506 9965 000 12285 LEAF SWITCH LSA-1142AU 1 1 1 1 1 1 1
SW507 9965 000 08561 ROTARY MODE SWITCH SSS-43MD 1 1 1 1 1 1 1
MISCELLANEOUS
T001
h
9965 000 09203 PULSE TRANS SA-00901B 1 1 1 1 1 1 1
TP301 PCB JUMPER D0.6-P9.5 1 1 1 1 1 1 1
TP501 PCB JUMPER D0.6-P6.0 1 1 1 1 1 1 1
TP502 PCB JUMPER D0.6-P10.0 1 1 1 1 1 1 1
TP506 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1 1 1 1 1
TP507 PCB JUMPER D0.6-P6.0 1 1 1 1 1 1 1
TP508 PCB JUMPER D0.6-P23.0 1 1 1 1 1 1 1
TP751 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1 1 1 1 1
TU701 9965 000 12193 TUNER UNIT TMDG2-632A 1
TU701 9965 000 12256 TUNER UNIT TMDZ2-731A 1 1
TU701 9965 000 12265 TUNER UNIT TMDG2-631A 1 1 1 1
VR501 9965 000 05260 CARBON P.O.T. 100K OHM B 1 1 1 1 1 1 1
X301 9965 000 05629 X’TAL 4.433619MHZ 1 1 1 1 1 1 1
X501 9965 000 12194 X’TAL 12.000MHZ 1 1 1 1 1 1 1
X502 9965 000 12288 X’TAL 32.768KHZ(20PPM) 1 1 1 1 1 1 1
JACK CBA
2L022 4822 502 30752 SCREW, P-TIGHT M3X10 WASHER HEAD+ 1 1 1 1 1 1 1
A5 9965 000 12263 JACK BOARD(2-21P) HC470ED 1 1 1 1
A5 9965 000 12273 JACK BOARD(2-21P) HC475ED 1 1 1
CAPACITORS
C101 CHIP CERAMIC CAP. B K 2200PF/50V 1 1 1 1 1 1 1
C102 CHIP CERAMIC CAP. B K 2200PF/50V 1 1 1 1 1 1 1
C103 CHIP CERAMIC CAP. CH J 470PF/50V 1 1 1 1 1 1 1
C104 CHIP CERAMIC CAP. CH J 470PF/50V 1 1 1 1 1 1 1
C105 CHIP CERAMIC CAP. F Z 0.1UF/50V 1 1 1 1 1 1 1
C107 ELECTROLYTIC CAP. 1UF/50V M H7 1 1 1 1 1 1 1
C108 CHIP CERAMIC CAP. B K 1000PF/50V 1 1 1 1 1 1 1
C109 CHIP CERAMIC CAP. B K 2200PF/50V 1 1 1 1 1 1 1
C110 CHIP CERAMIC CAP. B K 2200PF/50V 1 1 1 1 1 1 1
C111 CHIP CERAMIC CAP. CH J 470PF/50V 1 1 1 1 1 1 1
C112 CHIP CERAMIC CAP. CH J 470PF/50V 1 1 1 1 1 1 1
C113 CHIP CERAMIC CAP. B K 2200PF/50V 1 1 1 1 1 1 1
C115 ELECTROLYTIC CAP. 100UF/16V M H7 1 1 1 1 1 1 1
C116 ELECTROLYTIC CAP. 470UF/6.3V M 1 1 1 1 1 1 1
C117 ELECTROLYTIC CAP. 470UF/6.3V M 1 1 1 1 1 1 1
DIODES
D101 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1 1 1 1 1
D102 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1 1 1 1 1
D103 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1 1 1 1 1
D105 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1 1 1 1 1
JK101 9965 000 12197 RGB CONNECTOR MRC-021V-01 1 1 1 1 1 1 1
JK102 9965 000 12197 RGB CONNECTOR MRC-021V-01 1 1 1 1 1 1 1
COILS
L101 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3 1 1 1 1 1 1 1
L121 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.3 1 1 1 1 1 1 1
TRANSISTORS
Q101 4822 130 42959 TRANSISTOR KTA1266(GR) 1 1 1 1 1 1 1
Q102 4822 130 42959 TRANSISTOR KTA1266(GR) 1 1 1 1 1 1 1
RESISTORS
1-16-22
