3087 3078 3006 3015 3022 3973 Version 12NC Description Drive IC 12NC Description
314107802251 PBAS HasLi-07A WAC7500/12 15K X 10K X X 10K 2MB EU, TM10_V1 242254200038
TUN A+F
ENG07815QF EUR B
HX8346 272217100572
LCD MODULE YB-
TG240320C13B Y
WAC7500/12
(314107910361)
314107802851 PBAS Hasli_07A WAC7500/12_TU_V2 15K X 10K X 10K X 2MB EU, TM10_V2 242254200049
TUN FM
ENG07826QF EUR B
HX8346 272217100572
LCD MODULE YB-
TG240320C13B Y
WAC7500/12
(314107910361)
314107802891 PBAS Hasli_07A WAC7500/37_TU_V2 15K X X 10K 10K X 2MB
USA,
TM10_V2
242254200048
TUN FM
ENG06840QF USA B
HX8346 272217100572
LCD MODULE YB-
TG240320C13B Y
WAC7500/37
(314107910451)
314107802221 PBAS Wessli_07 WAS7500/12 15K 10K 10K X X 10K 8MB EU, TM10_V1 242254200038
TUN A+F
ENG07815QF EUR B
HX8346 272217100573
LCD MODULE YB-
TG240320C12B Y
WAS7500/12
(867000030233)
314107802761 PBAS Wessli_07A WAS7500/12 15K 3K3 10K X X 10K 16MB EU, TM10_V1 242254200038
TUN A+F
ENG07815QF EUR B
HX8346 272217100573
LCD MODULE YB-
TG240320C12B Y
WAS7500/12
(867000030233)
314107802841 PBAS Wessli_07B WAS7500/12 15K 3K3 10K X 10K X 16MB EU, TM10_V2 242254200049
TUN FM
ENG07826QF EUR B
HX8346 272217100573
LCD MODULE YB-
TG240320C12B Y
WAS7500/12
(867000030233)
314107802911 PBAS wessli_07B WAS7500/37 15K 3K3 X 10K 10K X 16MB
USA,
TM10_V2
242254200048
TUN FM
ENG06840QF USA B
HX8346 272217100573
LCD MODULE YB-
TG240320C12B Y
WAS7500/37
(867000034428)
314107803081 PBAS HasLi-07B WAC7500/12 27K 3K3 10K X 10K X 2MB EU, TM10_V2 242254200049
TUN FM
ENG07826QF EUR B
HX8347 272217100599
LCD MODULE YB-
TG240320C13C Y
WAC7500/12
(314107910361)
314107803091 PBAS HasLi-07B WAC7500/37 27K 3K3 X 10K 10K X 2MB
USA,
TM10_V2
242254200048
TUN FM
ENG06840QF USA B
HX8347 272217100599
LCD MODULE YB-
TG240320C13C Y
WAC7500/37
(314107910451)
314107803121 PBAS WessLi-07C WAS7500/12 3K3 27K 10K X 10K X 16Mb EU, TM10_V2 242254200049
TUN FM
ENG07826QF EUR B
HX8347 272217100601
LCD MODULE YB-
TG240320C12C Y
WAS7500/12
(867000030233)
314107803131 PBAS WessLi-07C WAS7500/37 3K3 27K X 10K 10K X 16MB
USA,
TM10_V2
242254200048
TUN FM
ENG06840QF USA B
HX8347 272217100601
LCD MODULE YB-
TG240320C12C Y
WAS7500/37
(867000034428)
WAC7500/12 : 314107802251 (PB-Hasli-07A) is used from 07.06.2007 to 15.06.2008 in production WAC7500/37 314107802891 (PB-Hasli-07A) is used from 10.12.2007 to 15.06.2008 in production
314107802851 (PB-Hasli-07A) is used from 15.06.2008 to 17.07.2008 in production 314107803091 (PB-Hasli-07B) is used from 17.07.2008 in production
314107803081 (PB-Hasli-07B) is used from 17.07.2008 in production
242254200038 (Tuner module) is used from 07.06.2007 to 15.06.2008 in production
242254200049 (Tuner module) is used from 15.06.2008 in production
272217100572 (LCD module) is used from 07.06.2007 to 17.07.2008 in production 272217100572 (LCD module) is used from 10.12.2007 to 17.07.2008 in production
272217100599 (LCD module) is used from 17.07.2008 in production 272217100599 (LCD module) is used from 17.07.2008 in production
WAS7500/12 : 314107802761 (PB-Hasli-07A) is used from 06.10.2007 to 15.06.2008 in production WAS7500/37 :
314107802841 (PB-Hasli-07B) is used from 15.06.2008 to 17.07.2008 in production 314107802911 (PB-Hasli-07B) is used from 10.12.2007 to 17.07.2008 in production
314107803121 (PB-Hasli-07B) is used from 17.07.2008 in production 314107803131 (PB-Hasli-07B) is used from 15.04.2008 in production
242254200038 (Tuner module) is used from 07.06.2007 to 15.06.2008 in production
242254200049 (Tuner module) is used from 15.06.2008 in production
272217100573 (LCD module) is used from 07.06.2007 to 17.07.2008 in production 272217100573 (LCD module) is used from 10.12.2007 to 17.07.2008 in production
272217100601 (LCD module) is used from 17.07.2008 in production 272217100601 (LCD module) is used from 17.07.2008 in production
TIPS: Old Hasli Board can be used by modify the resister 3087,3078,3006,3015,3022,3973 (has been marked in the diagrams of the service manual) when adopt the new Tuner module or LCM module.
Version setting in Melody PBAS
Flash
Memory
size in
Melody
module
Tuner module LCD module
Technical Set
Software
Version
V1 V2 V3
SW version
should be
V1.18 or
later.
Variant for WACS7500
PBAS 12NC of
Melody
module
Description of Melody PBAS
