19
5.4. Motor with brake
If a motor with a brake (connection in the mechanical motor brake) is connected, the 400 V AC brake must
be connected to the 2/T1 and 6/T3 connections. A 230 V AC-brake should be connected to the
4/T2 connection and the star point of the motor.
Please note: The motor current monitoring must be increased by the value of the brake (nominal
current brake). Set this as per the hybrid motor starter (see Item 4.3, page 18)!
5.5. Auxiliary relay connection
Auxiliary relay (e.g. PLC RSC 230UC/21, Order No.: 2966207) for activating the external brakes or
feedback to the PLC must be connected to the connections "4T2" and "N" of the system.
6. Technical data
Type Order No. ELR H5-IES-SC- 24DC/500AC-0,6 2900582
ELR H5-IES-SC- 24DC/500AC-2 2900414
ELR H5-IES-SC- 24DC/500AC-9 2900421
ELR H5-IES-SC-230AC/500AC-0,6 2900692
ELR H5-IES-SC-230AC/500AC-2 2900420
ELR H5-IES-SC-230AC/500AC-9 2900422
Input data ELR...-24DC/... ELR...-230AC/...
Rated control supply voltage U
s
as per IEC 60947-1 / UL 508/UL 60947-4-1A/UL 60947-1
24 V DC 230 V AC (50/60 Hz)
Control supply voltage range 19.2 ... 30 V DC
(32 V DC, max. 1 min.)
85 ... 253 V AC
Control supply voltage Switching level "Safe off" < 5 V DC < 5 V AC
Rated control supply current as per IEC 60947-1 ≤ 40 mA ≤4 mA
Control input L, R:
Switching level "Low" -3 ... 9.6 V DC < 44 V AC
Switching level "Safe off" < 5 V DC < 5 V AC
Switching level "High" 19.2 ... 30 V DC 85 ... 253 V AC
Input current ≤ mA ≤7 mA
Output data load side ELR...-0.6 ELR...-2 ELR...-9
Switching principle Safety end level with bypass, three-phase
electrically isolated switch-off
Rated operating voltage U
e
as per IEC 60947-1 500 V AC (50/60 Hz)
Operating voltage range as per IEC 60947-1
as per UL 508/UL 60947-4-1A/UL 60947-1
42...550 V AC
42...500 V AC
Load current at 20°C (see 8.2. Derating curve) 0.075...0.6 A 0.18...2.4 A 1,5... 9.0 A
Rated operating current I
e
as per IEC 60947-1
AC-51 as per IEC 60947-4-3
AC-53a as per IEC 60947-4-2
as per UL 508/UL 60947-4-1A/UL 60947-1
0.6 A
0.6 A
0.6 A
2.4 A
2.4 A
2.4 A
9 A
6.5 A
6.5 A
Nominal switching performance
as per UL 508/UL 60947-4-1A/UL 60947-1
Full Load (power factor = 0.4)
Full Load (power factor = 0.8)
0.3 kW (0.4 HP)
0.5 kW (0.6 HP)
0.9 kW (1.2 HP)
1.7 kW (2.2 HP)
2.3 kW (3.0 HP)
4.6 kW (6.1 HP)
Leakage current (input, output) 0 mA 0 mA 0 mA
Residual voltage at I
e
< 200 mV < 300 mV < 500 mV
