Phoenix Contact FL SWITCH 2008 Installation And Startup Guide

FL SWITCH 2000 / FL NAT 2000
206 / 226
PHOENIX CONTACT 108997_en_04
5.62 FL SWITCH 2608 PN
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 9 VDC ... 57 VDC
Typical current consumption 180 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 0.52 A (U
S
= min, T
amb
= max)
Maximum power dissipation for nominal condition 4.68 W (U
S
= min, T
amb
= max)
Test section for one minute 500 VDC
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
Vibration (operation) in acc. with IEC 60068-2-6: 5g, 150 Hz
Vibration (storage/transport) 5g, 150 Hz, in acc. with IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
Conformity with EMC directives
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Conducted noise emission EN 61000-6-3 (conducted emissions) Class B
Interference emission EN 61000-6-3 (conducted emissions) Class B
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion B
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Ordering data
Order designation FL SWITCH 2608 PN
Order No. 1106616
Pcs./Pkt. 1
Dimensions (nominal sizes in mm)
Width 60 mm
Height 226 mm
Depth 46 mm

Phoenix Contact FL SWITCH 2008 Specifications

General

Number of Ports	8
Port Type	RJ45
Technology	Ethernet
Power Supply	24 V DC
Mounting Type	DIN Rail
Switching Capacity	1.6 Gbps
Protection Class	IP20
Dimensions	45 mm x 130 mm x 95 mm (W x H x D)
Weight	0.3 kg
