Mounting and installation
108997_en_04 PHOENIX CONTACT 29 / 226
3.3.4 Installing the devices
3.3.4.1 Selecting the conductors
The devices are supplied with a Push-in connector.
Observe the specifications for suitable conductors and ferrules:
Table 3-8 Selection of conductors/ferrules
Conductor Push-in
Conductor cross-section, rigid, minimum 0.14 mm
2
Conductor cross-section, rigid, maximum 1.5 mm
2
Conductor cross-section, flexible, minimum 0.14 mm
2
Conductor cross-section, flexible, maximum 1.5 mm
2
Conductor cross-section, flexible, with ferrule without
plastic sleeve, minimum
0.25 mm
2
Conductor cross-section, flexible, with ferrule without
plastic sleeve, maximum
1.5 mm
2
Conductor cross-section, flexible, with ferrule with
plastic sleeve, minimum
0.25 mm
2
Conductor cross-section, flexible, with ferrule with
plastic sleeve, maximum
0.75 mm
2
Suitable ferrule without plastic sleeve:
maximum conductor cross-section
1.5 mm
2
Suitable ferrule without plastic sleeve:
maximum conductor cross-section
0.75 mm
2
(color code: gray in
accordance with DIN 46228)
Suitable screwdriver Slot-headed screwdriver
Blade thickness: 0.4 mm
Blade width: 2.5 mm
Recommended:
SZS 0,4X2,5 VDE,
Order No. 1205037
Conductor cross-section, AWG, minimum 24
Conductor cross-section, AWG, maximum 16
Stripping length 9 mm
Table 3-9 Specifications for ferrules
Recommended crimping
tool
1212034 CRIMPFOX 6
Ferrules without insulating col-
lar, in accordance with
DIN 46228-1
Cross-section: 0.25 mm
2
; Length: 7 mm
Cross-section: 0.34 mm
2
; Length: 7 mm
Cross-section: 0.5 mm
2
; Length: 8 mm … 10 mm
Cross-section: 0.75 mm
2
; Length: 8 mm … 10 mm
Cross-section: 1 mm
2
; Length: 8 mm … 10 mm
Cross-section: 1.5 mm
2
; Length: 10 mm
To Next Page
