FL SWITCH 2000
82
PHOENIX CONTACT 107065_en_01
SNMP Version 2c, Version 3
Transmission capacity per port
64-byte packet size, half duplex
At 10 Mbps: 14880 pps (packets per second)
At 100 Mbps: 148800 pps
At 1000 Mbps: 1488100 pps
Supported MIBs MIB II and private SNMP objects from Phoenix Contact
Housing dimensions (width x height x depth) in mm 45 x 130 x 115 (depth from top edge of DIN rail)
Permissible operating temperature -40°C to 70°C
Permissible storage temperature -40°C to +85°C
Degree of protection IP20 (not assessed in compliance with UL, assessed by PTL), IEC 60529
Protection class Class 3 VDE 0106; IEC 60536, for inside use only
Humidity
Operation 10% to 95%, non-condensing
Storage 10% to 95%, non-condensing
Air pressure
Operation 53 kPa to 108 kPa, 5000 m above sea level
Storage 53 kPa to 108 kPa, 5000 m above sea level
Ambient compatibility Free from substances that would hinder coating with paint or varnish accord-
ing to VW specification
Mounting position Perpendicular to a standard DIN rail
Connection to protective earth ground Snapped onto a grounded DIN rail
Pollution degree 2
Overvoltage category None
Weight Up to 310 g, typical
General data
Supply voltage (US1/US2 redundant)
Connection Via COMBICON; maximum conductor cross section = 1.5 mm
2
, use copper
wires that are suitable for 75°C or equivalent
Nominal value 24 V DC
Permissible voltage range 12 V DC to 57 V DC
Permissible ripple (within the permissible voltage range) 3.6 V
PP
Current consumption at US for 12 V DC, maximum 1.4 A (FL SWITCH 2308)
1.5 A (FL SWITCH 2304-2GC-2SFP)
1.5 A (FL SWITCH 2306-2SFP)
Current consumption at US for 24 V DC, maximum 280 mA (FL SWITCH 2308)
290 mA (FL SWITCH 2304-2GC-2SFP)
280 mA (FL SWITCH 2306-2SFP)
Test voltage 170 V DC for one minute
Interfaces
Number of Ethernet ports 8
Digital alarm output
Voltage 12 - 57 V DC
Current carrying capacity 100 mA, maximum 700 mA / 1 minute
