Technical data and ordering data
107065_en_01 PHOENIX CONTACT 83
Ethernet interfaces
Properties of the RJ45 ports
Number Up to 8 with auto crossing and auto negotiation
Connection format 8-pos. RJ45 socket on the switch
Connection medium Twisted pair cable
Cable impedance 100 ohms
Transmission speed 10/100/1000 Mbps
Maximum network segment expansion 100 m
Properties of the fiberglass ports
Number Up to 2
Connection format Gigabit SFP format
Connection medium Fiberglass
Connecting plug LC format (SFP module)
Transmission speed 100/1000 Mbps (depending on the SFP module used)
Maximum network segment expansion Depends on the SFP module/fiber type used
Fiber type Depends on the SFP module used
Laser protection class 1
Wavelength 850/1310/1550 nm (depending on the device/SFP module used)
Properties of the combo ports
Number Up to 2
Transmission speed 100/1000 Mbps
Wavelength Depends on the SFP module used
Maximum transmission length Depends on the SFP module used
Mechanical tests
Shock testing according to IEC 60068-2-27 Operation: 30g,
half-sine shock pulse
Vibration resistance according to IEC 60068-2-6 Operation/storage/transport: 5g, 10 Hz - 150 Hz
Free fall according to IEC 60068-2-32 1 m
Conformance with EMC Directives
Developed according to IEC 61000-6-2
Noise emission according to EN 55022: 1998
+ A1: 2000 + A2: 2003 (interference voltage)
Class A (industrial applications)
Noise emission according to EN 55011: 1998
+ A1: 1999 + A2: 2002 (electromagnetic interference)
Class A (industrial applications)
Noise immunity according to EN 61000-4-2 (IEC 1000-4-2) (ESD)
Contact discharge:
Air discharge:
Indirect discharge:
Requirements according to DIN EN 61000-6-2
Test intensity 3, criterion B
Test intensity 3, criterion A
Test intensity 3, criterion A
Noise immunity according to EN 61000-4-3 (IEC 1000-4-3)
(electromagnetic fields)
Requirements according to DIN EN 61000-6-2
Test intensity 3, criterion A
