VALUELINE IPC
2643_en_K PHOENIX CONTACT 6
Display - 12 in.
Screen size, diagonal 307 mm (12.1 in.)
Screen size, horizontal x vertical 246 x 185 mm
Resolution 800 x 600
Type Resistive touch screen
Brightness 400 Cd/m²
Number of colors 16.2 million
Contrast ratio 600:1
View angle, horizontal/vertical (CR=10), typ. 70°/60°
Installation cutout dimensions (width x height) 334 x 253 mm
Outside bezel dimensions (width x height x depth) 365 x 282 x 10 mm
Backlight life, minimum 50000 hr.
Interface (configurable option) USB 1.1/2.0, Type A
Mechanical tests
Shock test according to IEC 60068-2-27 15g, 11 ms impulse
Vibration resistance according to IEC 61131-2 Hard-disk drive: 0.5g
CompactFlash: 1.0g
Conformance with EMC directives
Developed according to IEC 61000-6-2
IEC 61000-4-2 (ESD) Criterion B
IEC 61000-4-3 (radiated-noise immunity) Criterion A
IEC 61000-4-4 (burst) Criterion B
IEC 61000-4-5 (surge) Criterion B
IEC 61000-4-6 (conducted noise immunity) Criterion A
IEC 61000-4-8 (noise immunity against magnetic fields) Criterion A
EN 55022 (noise emission) Class A
Approvals
Conformity c
Electromagnetic Compatibility Directive (EMC) 2004/108/EC
Listing
1
U UL 508
Hazardous Locations
2
U Class I, Division 2, Groups A, B, C, D
1
Configurations with a 18.5-, 21.5- and 24-in. display are not UL listed
2
Displays with front panel USB ports do not qualify with Class I, Division 2 listing
