11. Safety Shield
1. Insert left side of shield with spring pin into positioning holes on left side frame.
2. Insert right side pin into positioning hole on right side frame.
3. Lower safety shield onto side support pins.
4. Slide Safety Shield latch to the right and locked position to engage the
safety interlock switch
5. To release the latch, press the Red button on the lock
Warning: Ensure the safety shield is in place before operating the Laminator.
Operating without the safety shield can cause serious injury.
Note: The laminator will operate only when the Safety Shield and Feed Table are
in the fully locked position. Both the interlocking switches must be activated
for power to be supplied to the motor
