• Recommended settings below are for High temperature (210 F activation)
1.5 and 3 mil film and Low temperature (185 F activation) 5.0 and 10
mil film:
Dial Settings
Film Thickness Temperature Speed Approx. Temp display
1.5 mil 7 3 260° F
3.0 mil 7 2 260° F
5.0 mil with Fans ON 6 1.5 234° F
10 mil with Fans ON 6 1 234° F
3. Pouch board mounting
• Turn heater switch on rear panel to SINGLE position to turn off bottom heater.
(Allow 20-25 minutes for bottom roller to cool down)
• Rotate roller gap adjustment handle to position matching board thickness.
• Turn temperature dial clockwise to desired temperature setting.
• Turn speed dial clockwise to desired speed setting.
• Recommended settings for pouch boards is Temperature setting 10 and
Speed setting 1.5.
NOTE:
• Recommended settings are starting points only and should be adjusted
according to quality of output achieved.
• Excess heat may damage the printed image or cause waves. Insufficient
heat may result in delamination.
• Thinner stocks can be run faster, and thicker stocks or heavy ink coverage
should be run slower.
• Some stocks and ink-sets cannot be effectively laminated with thermal films.
Compatibility testing is recommended before laminating long runs.
WARNING: Ensure the safety shield is in place before operating the
Laminator. Operating without the safety shield can cause
serious injury.
