Unifarm Machinery Corporation
PO Box 38, Wilson, NC, U.S.A.
page 7
TECHNICAL DATA
MAIN PARTS TERMINOLOGY
A) Main Frame
B) Lower Hitch Blocks
C) Top Link Coupling
D) PTO Attach
E) Third Point Mast
F) Cover
G) Transmission Case
H) Wheel
Specifications M48-S M48-A M60-S M60-A M72-S M72-A M84-S M84-A
Tires Solid Air Solid Air Solid Air Solid Air
Cutting width 48’’ 60’’ 72’’ 84’’
Cutting height range ¾’’ - 4 ¼’’ 1 ½’’ - 4 ½’’
Blade Speed (rpm) 3130 2650 2240 2030
Blades number 3 3 3 3
HP max requirement 30 40 50 60
PTO Input (rpm) 540 540 540 540
Weight (lbs) 392 432 472 816
Gearbox Oil Type EP SAE 80W/90
Oil quantity (gal) 0,20
