Phonak ComPilot II How To Connect

Connecting to Computers/Tablets
WIRED IN (3.5 mm cable)
1. Switch ON your ComPilot II and place it around
your neck with your hearing aids on. Figure 1
2. Insert the audio cable into your
ComPilot II. Figure 2
3. Insert the other end of the audio cable into
the headphone socket of your audio device
(Computer/Tablet/Phone). Figure 2
4. Start the audio on your computer/tablet/phone
and the audio streaming will automatically start.
WITH YOUR TVLINK II
1. Ensure your TVLink II is paired with your
ComPilot II. For pairing instructions
CLICK HERE (see page 20-23)
2. Remove your TVLink II from your television,
if it has already been set up there, and
insert the 3.5 mm analog audio cable in
the back of the TVLink II. Figure 3
3. Insert the other end of the audio cable into
the headphone socket of your audio device
(Computer/Tablet/Phone). Figure 3
4. Ensure the TVLink II is plugged into a
power supply and turned on. Figure 4
5. Turn on your ComPilot II and place
it around your neck. Figure 1
6. Start the audio on your computer/tablet/phone
and the audio streaming will automatically start
AUDIO
Figure 1
Figure 2
Figure 3
Figure 4

Phonak ComPilot II Specifications

General

Bluetooth	Yes
Power source	Rechargeable battery
Water Resistance	No
Compatibility	Phonak hearing aids with a wireless connection
Streaming	Yes, audio streaming from Bluetooth devices and FM receivers
Remote Control	Yes, via app or device buttons
Microphone	Built-in microphone for phone calls
FM compatibility	Yes, with optional FM receiver
Audio input	3.5mm audio jack
Neckloop	Integrated
Operating Range	Up to 10 meters
Bluetooth Version	Bluetooth 2.1 + EDR
Charging Time	3 hours
