Button/diode/jack Function
Receiver
R1 Power on (hold for up to 5 seconds)•
Power off (hold for up to 5 seconds)•
Answering and ending mobile telephone •
calls
Answering and ending landline telephone •
calls
White light: WDA active•
Blue light: Bluetooth active•
Blue blink: Incoming call•
R2+ (up)
R2- (down)
Volume up•
Connect/disconnect WDA•
Volume down•
Reject mobile telephone call (hold for 2 •
seconds)
R3 Blue blink: Bluetooth not connected•
Green light: Volume level 1•
R4 Green light: Volume level 2•
R5
When in use
Red blink: Low battery •
Green light: Volume level 3•
When charging
Red light: Charging•
Green light: Fully charged•
R6 Green light: Volume level 4•
R7 White blink: WDA connection lost•
Green light: Volume level 5•
Quick list of functions
Button/diode/jack Function
R8 Jack for headphones•
R9 Jack for neck loop•
R10 Neck loop•
R11 Jack for charger•
Transmitter
T1 Power on/off, WDA and battery indicator•
T2 Omni-directional microphone. To pick up •
sound from different directions.
T3 Directional microphone. To pick up sound •
from one direction only.
T4 Jack for charger•
T5 Wrist strap hole•
T6 Belt clip•
T7 Neck strap hole•
Charger
C1 Charging stand for transmitter•
C2 Charging stand for receiver•
C3 Power and Bluetooth indicator•
C4 WDA channel selector•
C5 Bluetooth•
and WDA connecting button
C6 Jack for power supply•
C7 Sound input jack for television, radio, etc.•
C8 Jack for telephone in•
C9 Jack for telephone out•
Quick list of functions
