Phonic Ear hearlt all - Functions

C1
C3
7
C1: Charging stand for transmitter
C2: Charging stand for receiver
C3: Power and Bluetooth indicator
C4: WDA channel selector
C5: Bluetooth and WDA connecting/channel button
C6: 6V DC power supply jack
C7: Sound input jack for television, radio, MP3, etc.
C8: Telephone in jack
C9: Telephone out jack
Charger
Functions
C2
C4 C5 C6 C7 C8 C9
Receiver
6
Functions
R1: On/off switch and answering button,
WDA and Bluetooth indicator
R2: Volume button +/- (up/down)
R3: Bluetooth and volume level 1 indicator
R4: Volume level 2 indicator
R5: Battery and volume level 3 indicator
R6: Volume level 4 indicator
R7: WDA and volume level 5 indicator
R8: Headphones jack
R9: Neck loop jack
R10: Neck loop
R11: Charging jack
T1: On/off switch, WDA and
battery indicator
T2: Omni directional
microphone button with
indicator
T3: Directional microphone
button with indicator
T4: Charging jack
T5: Wrist strap hole
T6: Belt clip
T7: Neck strap hole
Transmitter
T3
T4
T6
T7
T1
T2
R4
R6
R11
R8
R1
R3
R5
R2
R7
R9
R10
T5
