Phonic AM55 - Appendix; D I M E N S I O N

7AM55/AM85/AM105/AM105FX/AM125/AM125FX
English Deutsch Español Français Português
日本語
日本語
简体中文
简体中文
THD
(Any output,
1KHz @ +14dBu,
20Hz to 20KHz,
channel inputs)
<0.005% <0.005% <0.005% <0.005% <0.005% <0.005%
CMRR
(1 KHz @
-60dBu, Gain at
maximum)
80dB 80dB 80dB 80dB 80dB 80dB
Maximum Level
Mic Preamp Input +10dBu +10dBu +10dBu +10dBu +10dBu +10dBu
All Other Input +21dBu +21dBu +21dBu +21dBu +21dBu +21dBu
Balanced Output +28dBu +28dBu +28dBu +28dBu +28dBu +28dBu
Impedance
Mic Preamp Input 2 K ohms 2 K ohms 2 K ohms 2 K ohms 2 K ohms 2 K ohms
All Other Input
(except insert)
10 K ohms 10 K ohms 10 K ohms 10 K ohms 10 K ohms 10 K ohms
RCA 2T Output 1.1 K ohms 1.1 K ohms 1.1 K ohms 1.1 K ohms 1.1 K ohms 1.1 K ohms
Ch Equalization
2-band, +/-15 dB 3-band, +/-15 dB 3-band, +/-15 dB 3-band, +/-15 dB 3-band, +/-15 dB 3-band, +/-15 dB
Low EQ 80 Hz 80 Hz 80 Hz 80 Hz 80 Hz 80 Hz
Mid EQ (mono
channel)
- 2.5 KHz 2.5 KHz 2.5 KHz 2.5 KHz 2.5 KHz
Hi EQ 12 KHz 12 KHz 12 KHz 12 KHz 12 KHz 12 KHz
Low cut filter
75Hz
(-18 dB/oct)
-
75Hz
(-18 dB/oct)
75Hz
(-18 dB/oct)
75Hz (-18dB/oct) 75Hz (-18dB/oct)
Built-in Power
Supply
100 VAC, 120 VAC,
220 ~ 240 VAC,
50/60 Hz
100VAC, 120VAC,
220 ~ 240VAC,
50/60Hz
100VAC, 120VAC,
220 ~ 240VAC,
50/60Hz
100VAC, 120VAC,
220 ~ 240VAC,
50/60Hz
100VAC, 120VAC,
220~240VAC,
50/60Hz
100VAC, 120VAC,
220~240VAC,
50/60Hz
Weight
0.63 kg
(1.40 lbs)
0.95 kg
(2.10 lbs)
1.50 kg
(3.3 lbs)
1.50 kg
(3.3 lbs)
1.77kg
(3.90 lbs)
1.77 kg
(3.90lbs)
Dimensions
(WxHxD)
120x54.3x175mm
(4.72"x2.13"x6.88")
145x56.9x234mm
(5.70"x2.24"x9.21")
175x62.8x236mm
(6.88"x2.47"x9.29")
175x62.8x236mm
(6.88"x2.47"x9.29")
216x62.8x236mm
(8.5"x2.47"x9.29")
216x62.8x236mm
(8.5"x2.47"x9.29")
