7
ssaBdiMhgiHnoitacilppAdiM/woLhgiH/diM
"81"01nroH"2~"1egatS005~0020005~0002
"51"01~5.6nroH"2~"1rotinoM/egatS008~0020005~0002
"21"5.6~4emoD"2~"1rotinoM0001~0030008~0003
"01"5.6~3emoD"2~"1rotinoM0001~0050008~0003
2.2 3-WAY SYSTEM (Ref:Figure 2)
PCR2213 is capable of single 3-way speaker system with one unit. The low/mid and mid/high crossover fre-
quency can be set between 80 to 8000Hz. Most 3-way system have low/mid crossover point at 200~2000Hz,
and mid/high at 800~8000Hz. Following are the table of popular 3-way configuration and recommended cross-
over frequency:
Figure 2:Typical Active 3-way System
To Next Page
