3
English
PHA 8800
SPECIFICATIONS
Audio Inputs
Main In HF-ltered, servo-balanced, 1/4" TRS connectors
Input Impedance 40 kΩ balanced, 20 kΩ unbalanced
Maximum input level +16 dBu balanced and unbalanced
CMRR typically 40 dB, >55 dB @1 kHz
DIRECT In 1/4" TRS connector (stereo)
Input Impedance 15 kΩ
Audio Outputs
Phones Outputs 1/4" TRS connector (stereo)
Power Amplier
Maximum Output Level +24 dBm (load impedance 100 Ω)
Minimum Output Load Impedance 100 Ω
System Specications
Frequency Response 10 Hz to 150 kHz, +/-3 dB
Noise 22 Hz to 22 kHz, < -90 dBu @ unit gain
Dynamic Range 22 Hz to 22 kHz: 110 dB
Distortion (THD) 0.006 % typical @ +4 dBu, 1 kHz @ unit gain
Function Controls
Input Level Variable
Output Level per Channel Variable
Function Switches
Main In 1 / Main In 2 Switches between Mian Input 1 and Main Input 2
Mono Swtiches this section to mono
Displays
Input Level 4-segment LED-display: -30/-12/0 dB/CLIP
Output Level 8-segment LED-display: -30/-24/-18/-12/-6/-3/0 dB/CLIP
Power Supply
Mains Voltage
USA/Canada 120V ~, 60 Hz
Europe/U.K./Australia 230V ~, 50 Hz
Japan 100V ~, 50-60 Hz
Power Consumption 30 W
Fuses
100-120 V ~, T630 mA H
200-240V ~, T315 mA H
Mains Connection Standard IEC receptacle
Dimensions 483 x 44 x 206 mm (19" x 1.7" x 8.1")
Net Weight 2.35 kg (5.19 lbs)
