3 Package
A special 3-stage package – transport package, outer package and protective film keeps
the in-vacuum and Cryo stepper motors from contamination, moisture and mechanical
damage.
3.1 Transportation Package
The transportation package is a cardboard box with moulded foam and bubble wrap.
Fig. 2 : Transportation package
3.2 Outer Package
The outer package is a gas-tight, evacuated foil package with the rating plate fixed. A pair
of safety gloves, a desiccant bag and the stepper motor are shrink-wrapped in the outer
package.
Fig. 3 : Outer packaging with rating plate
i
Outer package:
- Before opening the outer package:
Clean the outer package with a cleaning agent usual in vacuum
technology, e.g. IPA.
- Remove outer package just short before mounting the motor.
