CAUTION – Possible damage!
The leads of the motor:
- The leads from stepper motor to control terminals are not shielded
and therefore should be as short as possible!
- The leads of one motor phase, see Fig. 6, should be twisted pairs,
e.g. A and B, C and D (4-lead motor).
- The wires must not be stressed. Provide strain relief when twist-
ing, shortening or stripping the motor leads!
The motor's strain relief needs additional security when modifying
the wires.
