03_16
03_17
Battery (03_16, 03_17)
To access the battery, proceed as follows:
1. Place the scooter on its centre stand;
2. Open the saddle, following the procedure described above, see section "Opening
the saddle to reach the helmet compartment";
3. Remove retainers "A" and cover "B".
The battery is the electrical device that requires the most frequent inspections and
diligent maintenance. The main points of maintenance to be observed are as follows:
CAUTION
IN ORDER TO AVOID DAMAGING THE ELECTRICAL SYSTEM, NEVER DISCON-
NECT THE WIRING WHILE THE ENGINE IS RUNNING. DO NOT TIP THE SCOOT-
ER TOO MUCH IN ORDER TO AVOID DANGEROUS LEAKAGE OF BATTERY
ELECTROLYTE
.
Use of a new battery
Make sure that the terminals are connected correctly.
CAUTION
DO NOT REVERSE THE POLARITY: RISK OF SHORT CIRCUIT AND DAMAGE
TO THE ELECTRICAL SYSTEM.
46
