03_28
Helmet compartment lighting bulb (03_28)
Open the helmet compartment, take out the pressure mounted transparent cover
"D" and replace the bulb.
Rear-view mirrors
In order to remove the rear-view mirrors:
1. Remove the two screws «A» on the instrument panel upper section.
2. Remove the five screws «B» of the front handlebar cover.
3. Undo the three screws «C» fixing the windshield and collect the washers.
4. Loosen the lock nut «D» fixing the mirror and then remove the mirror.
To adjust the mirror, hold it and turn until it is adjusted to the adequate angle.
Front and rear disc brake
The brake disc and pad wear is automatically compensated, therefore it has no effect
on the functioning of the front and rear brakes. For this reason it is not necessary to
adjust the brakes. An excessively elastic brake lever stroke may indicate the presence
of air in the braking circuit or a failure in the braking system. In this case, mainly due
56
