light button, contacts for key
switch, button and switch for seat
opening, antitheft system
4 (10 A) Fuel injection remote control
5 (10 A) Light remote control
6 (3 A) Direct power supply to control
unit
03_20
FUSE 2
7 (7.5 A) Stop light, starter, light
remote control
8 (7.5 A) Horn, tail light, instrument
panel light, high-beam headlight (in
"Passing" mode)
9 (7.5 A) Direct power supply to
control unit, remote control for
electric fan
50
