CAUTION
USED OILS CONTAIN SUBSTANCES HARMFUL TO THE ENVIRONMENT. FOR
OIL REPLACEMENT, CONTACT AN AUTHORISED SERVICE CENTRE, WHICH
IS EQUIPPED TO DISPOSE OF USED OILS IN AN ENVIRONMENTALLY FRIEND-
LY AND LEGAL WAY.
Recommended products
AGIP CITY HI TEC 4T
Engine oil
SAE 5W-40, API SL, ACEA A3, JASO MA Synthetic oil
Characteristic
Engine oil (at oil and filter change)
1.7 l
03_05
Hub oil level (03_05, 03_06)
Check the oil in the rear hub.
To check the rear hub oil level, proceed as follows:
1.Park the scooter on level ground and rest it on its centre stand.
2. Unscrew the oil dipstick «A», dry it with a clean cloth. Reinsert it and screw it tightly
into place.
3. Pull out the dipstick and check that the oil level is between the MIN and MAX ref-
erence marks. If the oil level is below the MIN notch, top up with the required amount
of hub oil.
4. Screw the dipstick back in, checking that it is locked in place.
38
3 Maintenance
