PIAGGIO BEVERLY Cruiser 500ie User Manual

Oil for 4-stroke engines
Cleaning the vehicle
In order to soften the dirt and mud deposited on the painted surfaces, use a low pres-
sure jet of water. Once softened, mud and dirt must be removed with a soft sponge
for bodywork soaked in lots of water and "shampoo" (2-4% of car shampoo in water).
Then rinse abundantly with water, and dry with a shammy cloth. Any polishing with
silicon wax must always be preceded by washing
CAUTION
DETERGENTS CAN POLLUTE WATER. THE VEHICLE MUST BE WASHED AT A
WASH STATION EQUIPPED WITH A SPECIAL WATER PURIFICATION SYSTEM.
WARNING
THE USE OF A HIGH-PRESSURE WATER JET IS STRONGLY DISCOURAGED
FOR ANY ENGINE CLEANING OPERATION; HOWEVER, IF NO OTHER MEANS
ARE AVAILABLE, IT IS THEN NECESSARY TO:
• ONLY USE THE FAN JET.
• DO NOT PLACE THE NOZZLE CLOSER THAN 60 CM.
• DO NOT USE WATER AT TEMPERATURES OVER 40ºC.
• DO NOT USE HIGH-PRESSURE WATER JETS.
• DO NOT STEAM WASH.
• DO NOT DIRECT THE JET AT: THE CARBURETTOR, THE ELECTRIC CABLES,
THE SLOT DIFFUSERS IN THE TRANSMISSION COVER AND THE SCROLL
COVER.
61
3 Maintenance

PIAGGIO BEVERLY Cruiser 500ie Specifications

General

Displacement	492 cc
Cooling System	Liquid cooled
Fuel System	Electronic injection
Transmission	Automatic CVT
Front Suspension	Telescopic hydraulic fork
Rear Brake	240 mm disc
Rear Tire	150/70-14
Width	780 mm
Seat Height	790 mm
Top Speed	160 km/h
Engine Type	Single cylinder, 4-stroke
Rear Suspension	Double hydraulic shock absorber
Front Brake	260 mm disc
Front Tire	110/70-16
