- Move the rocker and replace the interested pad,
correcting the clearance in the pre-set value.
N.B.
INSERT THE CALIBRATED PADS WITH THE WORDS SIDE
VALVE IN ORDER TO PRESERVE THE INDICATION OF
THICKNESS OVER TIME.
THE OUTLET ROCKER SLIDES ON THE AXIS ONLY AF-
TER THE INTAKE ROCKER HAS BEEN MOVED. MAKE
SURE THAT THE PADS DO NOT FALL INSIDE THE ENGINE
COMPARTMENT.
Characteristic
Valve clearance (cold engine)
Intake: 0.10 mm Exhaust: 0.15 mm
- Insert the rockers lock.
- Fit the valve cover.
Engine MP3 400 hpe E5
ENG - 100
