- Insert the Seeger ring.
- Insert the alignment dowels if removed during
disassembly.
Removing the driven pulley
To remove the driven pulley, proceed as follows:
- Remove the drive pulley to release the drive belt.
- Remove the driven pulley together with the belt.
WARNING
AS A RESULT OF THE OPERATION THERE MAY BE A
LIGHT "HAMMERING" BETWEEN THE KNURLING OF THE
PULLEY AXLE. THIS CAN MAKE REMOVAL BY HAND DIF-
FICULT.
IN CASE OF NEED USE AN EXTRACTOR.
Inspecting the clutch drum
- To remove the housing from the driven pulley
shaft it is necessary to remove the complete clutch
assembly from the engine as described in section
«Disassembling the clutch».
- Remove the protection caulking.
Engine MP3 400 hpe E5
ENG - 40
