- Replace according to the scheduled maintenance table.
Removing the driving pulley
- Using specific tools, lock the driving pulley and
loosen the flanged nut.
Specific tooling
020442Y Pulley lock wrench
- remove the flat washer and the cup washer.
- remove the stationary half-pulley and the washer.
- disengage the belt.
- remove the complete roller housing.
Engine MP3 400 hpe E5
ENG - 62
