- Using the specific tool to maintain the clutch
housing in position, unscrew the nut to recover the
washer.
Specific tooling
020917Y Driven pulley stop
- Remove the housing from the shaft.
- To fit, follow the removal steps but in reverse order, being careful to tighten to the specified torque.
CAUTION
ALWAYS USE A NEW NUT FOR RETAINING THE CLUTCH OUTPUT SHAFT, THEN PROCEED TO
THE CAULKING.
Locking torques (N*m)
Clutch output shaft nut 120 to 130
MP3 400 hpe E5 Engine
ENG - 41
