- Unscrew the two screws and remove the ten-
sioner pad
- Remove the oil pump command sprocket com-
plete with chain.
- Undo the fastening screws of the oil pump.
- Remove the oil pump and collect the gasket.
Engine MP3 400 hpe E5
ENG - 116
