- Using the special tool and appropriate supports,
ensure a proper support surface. Using a hammer
and a plug (of diameter less than 8 mm and being
careful not to damage the shaft seat) remove the
shaft and ceramic seal.
Specific tooling
001467Y002 Driver for OD 73 mm bearing
- Supporting the ceramic seal properly, remove the
impeller shaft, acting from the mobile side of the
seal.
MP3 400 hpe E5 Engine
ENG - 121
