- Remove the gasket.
Removing the flywheel cover components
- Disconnect the spark plug cap.
- Undo the two fixing screws of the coil.
- Loosen the two clamps and remove the coolant
internal recirculation pipe.
- Undo the four screws «A» and the fixing screw
«B» of the coolant pump cover.
MP3 400 hpe E5 Engine
ENG - 77
