Removing the timing system drive
- Before working on the timing system it is recom-
mended to place the engine at TDC in compres-
sion, aligning the references as shown in the
figure.
- First loosen the tensioner and unscrew the fixing
screws.
- Remove the tensioner complete with gasket.
Engine MP3 400 hpe E5
ENG - 86
