Pickering 41-670 User Manual

Page v
PXI/PXIe LVDT/RVDT/Resolver Simulator Module 41/43-670
pickering
Copyright Statement ...................................................................ii
Technical Support and Warranty ................................................iii
Contents (this page) ....................................................................v
Section 1
Technical Specication ...............................................................1.1
Section 2
Technical Description .................................................................2.1
Functional Description ..........................................................2.1
Simulation Congurations ....................................................2.2
Section 3
Installation ....................................................................................3.1
Pre-Operation Checks ...........................................................3.1
Hardware Installation ............................................................3.2
Software Installation .............................................................3.2
Testing Operation ..................................................................3.3
Section 4
Programming Guide ....................................................................4.1
Programming Options For Pickering PXI/PXIe Modules ...4.1
Using the Simulator Module .................................................4.3
Programming the Input/Output Switches ............................4.19
Programming Control - C# Functions .................................4.21
Section 5
Connector Information ................................................................5.1
Section 6
Trouble Shooting .........................................................................6.1
Section 7
Maintenance Information ............................................................7.1
Software Update ....................................................................7.1
Verication Procedure ..........................................................7.2
Relay Look-Up Table .............................................................7.13
CONTENTS

Pickering 41-670 Specifications

General

Brand	Pickering
Model	41-670
Category	Control Unit
Language	English
