SECTION 1 - TECHNICAL SPECIFICATION
Page 1.3
PXI/PXIe LVDT/RVDT/Resolver Simulator Module 41/43-670
pickering
LVDT/RVDT/Resolver Simulator, 41/43-670
pickeringtest.com
Specifications & Ordering Information
Mating Connectors & Cabling
For connection accessories for the 41/43-670 module
please refer to the 90-005D 50-pin D-type Connector
Accessories data sheet where a complete list and
documentation can be found for accessories, or refer to
the Connection Solutions catalog.
Product Order Codes
PXI LVDT/RVDT/Resolver
Simulator Module 41-670-XYZ-AABBCC
PXIe LVDT/RVDT/Resolver
Simulator Module 43-670-XYZ-AABBCC
Product Customization
Pickering modules are designed and manufactured on our
own flexible manufacturing lines, giving complete product
control and enabling simple customization to meet very
specific requirements.
All customized products are given a unique part number,
fully documented and may be ordered at any time in the
future. Please contact your local sales office to discuss.
Product Order Code - Key
X = Functionality 0 = LVDT/RVDT/Resolver
1 = LVDT/RVDT only
2 = Resolver only
Y = Reserved 0
Z = Density 1 = 4 banks
3 = 2 banks
AA = Input Voltage Range 01 = 1.8 V
02 = 3.6 V
03 = 7.2 V
04 = 19 V
05 = 38 V
BB = Reserved 00
CC = Output Voltage Range 01 = 1.8 V
02 = 3.8 V
03 = 7.7 V
04 = 15.5 V
05 = 31 V
Example Part Numbers:
41-670-001-020002
(PXI LVDT/RVDT/Resolver Simulator with 4-Banks, 3.6 V
Input, 3.8 V Output)
41-670-001-030003
(PXI LVDT/RVDT/Resolver Simulator with 4-Banks, 7.2 V
Input, 7.7 V Output)
43-670-001-040004
(PXIe LVDT/RVDT/Resolver Simulator with 4-Banks, 19 V
Input, 15.5 V Output)
Operating/Storage Conditions
Operating Conditions
Operating Temperature:
Humidity:
Altitude:
0 °C to +55 °C
Up to 90 % non-condensing
5000 m
Storage and Transport Conditions
Storage Temperature:
Humidity:
Altitude:
-20 °C to +75 °C
Up to 90 % non-condensing
15000 m
PXI & CompactPCI Compliance - 41-670
The module is compliant with the PXI Specification 2.2.
Local Bus, Trigger Bus & Star Trigger are not implemented.
Uses a 33 MHz 32-bit backplane interface.
PXIe Compliance - 43-670
The module is compliant with the PXIe Specification 1.0.
Local Bus, Trigger Bus & Star Trigger are not implemented.
Safety & CE Compliance
All modules are fully CE compliant and meet applicable
EU directives: Low-voltage safety EN61010-1:2010,
EMC Immunity EN61326-1:2013,
Emissions EN55011:2009+A1:2010.
