Page 4.6
SECTION 4 - PROGRAMMING GUIDE
pickering
ISOLATED MILLIVOLT THERMOCOUPLE SIMULATOR 41-761
Table 4.3 – Sub-Unit Bit Usage: Isolation Switches
For 32-Channel Version (41-761-001)
Sub-Unit Bit Function Sub-Unit Bit Function
33 1 Vo1 isolation 33 33 Vo17 isolation
33 2 Vcold1 isolation 33 34 Vcold17 isolation
33 3 Vo2 isolation 33 35 Vo18 isolation
33 4 Vcold2 isolation 33 36 Vcold18 isolation
33 5 Vo3 isolation 33 37 Vo19 isolation
33 6 Vcold3 isolation 33 38 Vcold19 isolation
33 7 Vo4 isolation 33 39 Vo20 isolation
33 8 Vcold4 isolation 33 40 Vcold20 isolation
33 9 Vo5 isolation 33 41 Vo21 isolation
33 10 Vcold5 isolation 33 42 Vcold21 isolation
33 11 Vo6 isolation 33 43 Vo22 isolation
33 12 Vcold6 isolation 33 44 Vcold22 isolation
33 13 Vo7 isolation 33 45 Vo23 isolation
33 14 Vcold7 isolation 33 46 Vcold23 isolation
33 15 Vo8 isolation 33 47 Vo24 isolation
33 16 Vcold8 isolation 33 48 Vcold24 isolation
33 17 Vo9 isolation 33 49 Vo25 isolation
33 18 Vcold9 isolation 33 50 Vcold25 isolation
33 19 Vo10 isolation 33 51 Vo26 isolation
33 20 Vcold10 isolation 33 52 Vcold26 isolation
33 21 Vo11 isolation 33 53 Vo27 isolation
33 22 Vcold11 isolation 33 54 Vcold27 isolation
33 23 Vo12 isolation 33 55 Vo28 isolation
33 24 Vcold12 isolation 33 56 Vcold28 isolation
33 25 Vo13 isolation 33 57 Vo29 isolation
33 26 Vcold13 isolation 33 58 Vcold29 isolation
33 27 Vo14 isolation 33 59 Vo30 isolation
33 28 Vcold14 isolation 33 60 Vcold30 isolation
33 29 Vo15 isolation 33 61 Vo31 isolation
33 30 Vcold15 isolation 33 62 Vcold31 isolation
33 31 Vo16 isolation 33 63 Vo32 isolation
33 32 Vcold16 isolation 33 64 Vcold32 isolation
