ISOLATED MILLIVOLT THERMOCOUPLE SIMULATOR 41-761
APPENDIX B: SUB-UNIT & BIT USAGE - 24-CHANNEL VERSION
Table 4.4 – Sub-Unit Usage: Voltage Sources
For 24-Channel Version (41-761-002)
Sub-Unit Bit Function
1 — Voltage Source 1
2 — Voltage Source 2
3 — Voltage Source 3
4 — Voltage Source 4
5 — Voltage Source 5
6 — Voltage Source 6
7 — Voltage Source 7
8 — Voltage Source 8
9 — Voltage Source 9
10 — Voltage Source 10
11 — Voltage Source 11
12 — Voltage Source 12
13 — Voltage Source 13
14 — Voltage Source 14
15 — Voltage Source 15
16 — Voltage Source 16
17 — Voltage Source 17
18 — Voltage Source 18
19 — Voltage Source 19
20 — Voltage Source 20
21 — Voltage Source 21
22 — Voltage Source 22
23 — Voltage Source 23
24 — Voltage Source 24
