Pickering 41-761 - Page 28

Page 4.8
SECTION 4 - PROGRAMMING GUIDE
pickering
ISOLATED MILLIVOLT THERMOCOUPLE SIMULATOR 41-761
Table 4.5 – Sub-Unit Bit Usage: Isolation Switches
For 24-Channel Version (41-761-002)
Sub-Unit Bit Function Sub-Unit Bit Function
25 1 Vo1 isolation 25 33 Vo17 isolation
25 2 Vcold1 isolation 25 34 Vcold17 isolation
25 3 Vo2 isolation 25 35 Vo18 isolation
25 4 Vcold2 isolation 25 36 Vcold18 isolation
25 5 Vo3 isolation 25 37 Vo19 isolation
25 6 Vcold3 isolation 25 38 Vcold19 isolation
25 7 Vo4 isolation 25 39 Vo20 isolation
25 8 Vcold4 isolation 25 40 Vcold20 isolation
25 9 Vo5 isolation 25 41 Vo21 isolation
25 10 Vcold5 isolation 25 42 Vcold21 isolation
25 11 Vo6 isolation 25 43 Vo22 isolation
25 12 Vcold6 isolation 25 44 Vcold22 isolation
25 13 Vo7 isolation 25 45 Vo23 isolation
25 14 Vcold7 isolation 25 46 Vcold23 isolation
25 15 Vo8 isolation 25 47 Vo24 isolation
25 16 Vcold8 isolation 25 48 Vcold24 isolation
25 17 Vo9 isolation
25 18 Vcold9 isolation
25 19 Vo10 isolation
25 20 Vcold10 isolation
25 21 Vo11 isolation
25 22 Vcold11 isolation
25 23 Vo12 isolation
25 24 Vcold12 isolation
25 25 Vo13 isolation
25 26 Vcold13 isolation
25 27 Vo14 isolation
25 28 Vcold14 isolation
25 29 Vo15 isolation
25 30 Vcold15 isolation
25 31 Vo16 isolation
25 32 Vcold16 isolation
