Page 4.10
SECTION 4 - PROGRAMMING GUIDE
pickering
ISOLATED MILLIVOLT THERMOCOUPLE SIMULATOR 41-761
Table 4.7 – Sub-Unit Bit Usage: Isolation Switches
For 16-Channel Version (41-761-003)
Sub-Unit Bit Function
17 1 Vo1 isolation
17 2 Vcold1 isolation
17 3 Vo2 isolation
17 4 Vcold2 isolation
17 5 Vo3 isolation
17 6 Vcold3 isolation
17 7 Vo4 isolation
17 8 Vcold4 isolation
17 9 Vo5 isolation
17 10 Vcold5 isolation
17 11 Vo6 isolation
17 12 Vcold6 isolation
17 13 Vo7 isolation
17 14 Vcold7 isolation
17 15 Vo8 isolation
17 16 Vcold8 isolation
17 17 Vo9 isolation
17 18 Vcold9 isolation
17 19 Vo10 isolation
17 20 Vcold10 isolation
17 21 Vo11 isolation
17 22 Vcold11 isolation
17 23 Vo12 isolation
17 24 Vcold12 isolation
17 25 Vo13 isolation
17 26 Vcold13 isolation
17 27 Vo14 isolation
17 28 Vcold14 isolation
17 29 Vo15 isolation
17 30 Vcold15 isolation
17 31 Vo16 isolation
17 32 Vcold16 isolation
