Pickering 41-761 - SECTION 4 - PROGRAMMING GUIDE; APPENDIX D: SUB-UNIT & BIT USAGE - 8-CHANNEL VERSION

SECTION 4 - PROGRAMMING GUIDE
Page 4.11
pickering
ISOLATED MILLIVOLT THERMOCOUPLE SIMULATOR 41-761
APPENDIX D: SUB-UNIT & BIT USAGE - 8-CHANNEL VERSION
Table 4.8 – Sub-Unit Usage: Voltage Sources
For 8-Channel Version (41-761-004)
Sub-Unit Bit Function
1 — Voltage Source 1
2 — Voltage Source 2
3 — Voltage Source 3
4 — Voltage Source 4
5 — Voltage Source 5
6 — Voltage Source 6
7 — Voltage Source 7
8 — Voltage Source 8
Table 4.9 – Sub-Unit Bit Usage: Isolation Switches
For 8-Channel Version (41-761-004)
Sub-Unit Bit Function
9 1 Vo1 isolation
9 2 Vcold1 isolation
9 3 Vo2 isolation
9 4 Vcold2 isolation
9 5 Vo3 isolation
9 6 Vcold3 isolation
9 7 Vo4 isolation
9 8 Vcold4 isolation
9 9 Vo5 isolation
9 10 Vcold5 isolation
9 11 Vo6 isolation
9 12 Vcold6 isolation
9 13 Vo7 isolation
9 14 Vcold7 isolation
9 15 Vo8 isolation
9 16 Vcold8 isolation
