ISOLATED MILLIVOLT THERMOCOUPLE SIMULATOR 41-761
Table 7.4 - Verication Test Results For +/-20mV Range (Accuracy: 0.1% ±5μV)
Serial Number:
Channel Number:
Date of Test:
Operator’s Name:
Test Equipment
Used:
Voltage (mV) Measured Value Maximum (mV) Minimum (mV)
Result (delete
as appropriate)
-20 -19.975 -20.025 Pass / Fail
-18 -17.977 -18.023 Pass / Fail
-16 -15.979 -16.021 Pass / Fail
-14 -13.981 -14.019 Pass / Fail
-12 -11.983 -12.017 Pass / Fail
-10 -9.985 -10.015 Pass / Fail
-8 -7.987 -8.013 Pass / Fail
-6 -5.989 -6.011 Pass / Fail
-4 -3.991 -4.009 Pass / Fail
-2 -1.992 -2.007 Pass / Fail
0 0.005 -0.005 Pass / Fail
2 2.007 1.993 Pass / Fail
4 4.009 3.991 Pass / Fail
6 6.011 5.989 Pass / Fail
8 8.013 7.987 Pass / Fail
10 10.015 9.985 Pass / Fail
12 12.017 11.983 Pass / Fail
14 14.019 13.981 Pass / Fail
16 16.021 15.979 Pass / Fail
18 18.023 17.977 Pass / Fail
20 20.025 19.975 Pass / Fail
Note: The maximum and minimum values listed do not take into account test equipment uncertainty, values are provided for
convenience only. Only a high performance measuring device should be used to minimize the additional uncertainty.
