DC Voltage Read
Range and Accuracy
0.00 to 80.00 mV, ≤ ±(0.03% of Full Scale)
0 to 10.25 V, ≤ ±(0.03% of FS + 0.005V)
0.0 to 60.0 V, ≤ ±(0.03% of FS + 0.05V)
Input resistance ≥ 1 MΩ
Source V dc
Range & Accuracy
-
10.00 to 80.00 mV, ≤ ± (0.03% of Full Scale)
0.00 to 10.25 V, ≤ ± (0.03% of FS +0.005V)
Source Current
≥ 24 mA
Sink Current > 16 mA
Output Impedance < 1 Ohm
Short Circuit Duration Infinite
Thermocouple Source
Accuracy ±(0.03% of Full Scale)
[Note: Full Scale is 80.00 mV]
Cold Junction Compensation
±0.1°C (Thermistor traceable to NIST
for 11 years)
Output Impedance < 1 Ohm
Source Current > 20 mA (drives 80 mV into 10 Ohms)
Specifications
