-1.1 to 400.0 ±2.5° 30.0 to 752.0 ±4.5°
400.0 to 1500.0 ±1.3° 752.0 to 2732.0 ±2.4°
1500.0 to 2000.0 ±2.3° 2732.0 to 3632.0 ±3.0°
2000.0 to 2320.0 ±2.6° 3632.0 to 4208.0 ±4.6°
P
Platinel
0.0 to 150.0 ±0.8° 32.0 to 302.0 ±1.5°
150.0 to 1100.0 ±0.6° 302.0 to 2012.0 ±1.1°
1100.0 to 1395.0 ±0.8° 2012.0 to 2543.0 ±1.5°
L
J-DIN
-200.0 to 0.0 ±0.7° -328.0 to 32.0 ±1.3°
0.0 to 550.0 ±0.5° 32.0 to 1022.0 ±0.8°
550.0 to 900.0 ±0.4° 1022.0 to 1652.0 ±0.7°
U
T-DIN
-200.0 to -25.0 ±1.4° -328.0 to -13.0 ±2.6°
-25.0 to 100.0 ±0.7° -13.0 to 212.0 ±1.2°
100.0 to 300.0 ±0.5° 212.0 to 572.0 ±0.9°
300.0 to 600.0 ±0.4° 572.0 to 1112.0 ±0.7°
T/C Degrees C
Range
°C Degrees F
Range
°F
Thermocouple Ranges & Accuracies
Table based on Accuracy:
≤ ± (0.03 % of 80 mV)
Note: Doesn’t include cold junction error of ±0.1°C
