Page 6
Operating Instructions
Double Click Menus
MAIN
> EXIT (1/2)
FUNCTION mA
MODE SOURCE 2W SIM
UNITS mA %
HART 250Ω ON OFF
> EXIT (1/2)
FUNCTION V
RANGE 10V 80mV
> EXIT (1/2)
FUNCTION mA
MODE READ PWR MEAS
UNITS mA %
HART 250Ω ON OFF
Double click the EZ-DIAL knob to access the Double Click
Menus to select each function and the options for each function.
Available choices are shown in grey.
> EXIT (1/2)
FUNCTION V
RANGE 10V 60V 80mV
Source mA & Simulate 2 Wire Transmitters
Read mA & Power/Measure Transmitters
Source Volts & Millivolts
Read Volts & Millivolts
> EXIT (1/2)
FUNCTION FREQ
RANGE 20KHZ 10000HZ 1000HZ 2000CPM
Source & Read Frequency
To Next Page
