PIE PIECAL 820 - Page 9

Page 7
> EXIT (1/2)
FUNCTION T/C
UNITS °C °F
T/C TYPE J K E T R S B N L U G C D P
COLD JUNC ON
> EXIT (1/2)
FUNCTION RTD
UNITS °C °F
RTD Pt 100 a=3850 [* RTD Types]
WIRE MODE 234W
> EXIT (1/2)
FUNCTION RTD
UNITS °C °F
RTD Pt 100 a=3850 [* RTD Types]
WIRE MODE 3W 2W 4W
* RTD Types: Pt 100 a=3850, a=3902, a=3916, a=3926
Pt 1000 a=3850; Cu 10 a=4274, Cu 50 a=4280
Ni 120 a=6720, Ni 110 a=5801
Source & Read Thermocouples
Source RTD
Operating Instructions
Double Click Menus
Read RTD
>EXIT (1/2)
FUNCTION OHMS
RANGE 400Ω 4000Ω
WIRE MODE 234W
>EXIT (1/2)
FUNCTION OHMS
RANGE 400Ω 4000Ω CONT
WIRE MODE 3W 2W 4W
Source Ohms
Read Ohms
